Guide: How to disable ping on WAN interfaces

Follow

Comments

7 comments

  • Avatar
    Chris G

    Any plans to make this persistent?

    0
    Comment actions Permalink
  • Avatar
    Michael Bierman

    Seems to be broken for dual lan configuration

    pi@firewalla:~ (Firewalla) $ sudo iptables -A FW_INPUT_DROP -i $(frcc | jq -r '.routing.global.default.viaIntf') -p icmp -j FW_DROP

    jq - commandline JSON processor [version 1.5-1-a5b5cbe]

    Usage: jq [options] <jq filter> [file...]



    jq is a tool for processing JSON inputs, applying the

    given filter to its JSON text inputs and producing the

    filter's results as JSON on standard output.

    The simplest filter is ., which is the identity filter,

    copying jq's input to its output unmodified (except for

    formatting).

    ...


    But this seems to work

    sudo iptables -A FW_INPUT_DROP -i eth0 -p icmp -j FW_DROP

    sudo iptables -A FW_INPUT_DROP -i eth1 -p icmp -j FW_DROP



    0
    Comment actions Permalink
  • Avatar
    Support

    Thanks for the feedback. Yes, it does not support dual WAN currently. And the alias of frcc is changed in 1.971. We will eventually make this configurable via the app.

    0
    Comment actions Permalink
  • Avatar
    Kunnado

    I had to replace $() with eth0

    BTW as soon as I ran this command, the WAN network ping test failed. The WAN network now has a red dot and I got an alarm saying "internet connectivity change" and that the connectivity was down. Haven't lost connectivity though.

    0
    Comment actions Permalink
  • Avatar
    Michael Bierman

    I believe

    sudo iptables -A FW_INPUT_DROP -i eth0 -p icmp --icmp-type 8 -j FW_DROP

    should work for single WAN.

    Add

    sudo iptables -A FW_INPUT_DROP -i eth1 -p icmp --icmp-type 8 -j FW_DROP

    if you are using dual WAN.

    I put these in a startup script in

    /home/pi/.firewalla/config/post_main.d

    until Firewalla makes this configurable.



    keep in mind this assumes that you are using FW ports 4 and 3. If you change which ports are your WAN you need to change the the choices accordingly.

    0
    Comment actions Permalink
  • Avatar
    Kunnado

    that did the trick. the key was "icmp-type 8" Thank you.

    0
    Comment actions Permalink
  • Avatar
    Michael Bierman

    Glad it worked. All credit goes to Firewalla! I just passed it along.

    0
    Comment actions Permalink
