Help us make the Firewalla Switch
The Spec is pending and needs your requirements
-
I agree, 16 ports, 2.5gb ports, maybe 1 or 2 10gb ports to allow for WiFi 7 and the gold pro. I feel if you go with more 10gb ports it will get too expensive to buy and manufacture.
As far as POE goes. I would say half too. Depends where your market is home soho or office. If soho, like my situation, I don't think you need 16 POE ports!
Also I'm thinking of cost for buying the Pro, your AP and your switch. It has to be affordable as otherwise, what's the point
-
I think there should be 2 switches, one 8 port the size of the firewalla Gold Pro so it can be stacked on/under the firewall, and another 16 or 24 port for rack mounting for those that rack their firewalla.
Both products should have half the ports be poe+.
The 8 port should have 8 RJ45 ports and have 4-6 be 2.5gb ports and 2-4 10gb ports, with an additional 2 sfp+ 10gb ports to the side of the main RJ45 ports. At least two of the 10gb RJ45s need to be poe+ capable, along with a group of the 2.5gb ports being poe+ capable. This 8 port switch should have a 120 watt poe power supply in it. If it is an all 2.5gb, a pair of 10gb ports plus poe managed switch then the price should be around $250-300. If it doesn't have poe and looses the 10gb ports then price should be around $90-100 since that is the price of the same switches from China you will be competing against.
The 16-24 port switch should have 4 10gb RJ45 poe+ ports, and 8 2.5gb poe+ ports. The rest should be either 2.5gb or some 10gb non-poe ports. It should also have 2 sfp+ 10gb ports on the far side. This rackmount switch should have a 300 watt poe power supply. If this has the 10gb RJ45, 2.5gb RJ ports, as well as the poe and L3, then this could be priced around $450 to compete with the competitions offerings. If this looses the 10gb RJ45 ports but keeps the other stuff including L3, maybe around $350.
Typically switches now days list port count by how many RJ45 they have, and do not include the extra sfp ports included in the port count, and either include two 1gb SFP or two 10gb SFP+ ports for switch uplink
Down the road, once you have recouped investments into the initial switches, you can release a 3rd switch that is 24 port and all 10gb RJ45, with sfp28 ports on the side for the really high end networks. This one should have 8 ports of PoE+ and 4 ports of PoE++ and a 500w power supply.
The larger rack switch should be an L3 switch capable of handling vlan routing. The smaller stackable 8 port switch would be nice if it had L3, but Im fine if it is just L2
-
I do like the idea of an 8 port that could fit in a half 1u to share with the gold/gold pro.
16 and 24 port models would be awesome. With at least half the ports supporting PoE, maybe at least 4 on PoE +. Definitely would want to see at least 4 ports on 2.5gb. with 10gb ports for uplink. 2x 10gb for up and down links would be sweet. I'd love to see a 8 port all 10gb model to use for aggregation or on by homelab rack. On a aggregation switch sfp ports would be preferable to rj45. -
I have my FWG connected to a:
Cisco Meraki Go GS110-24PI'm using 14 ports currently so 16 would work. Its a 1U Rack-mountable (with included rack mount hardware) which is.perfect, it's Poe+ and id definitely need Poe as I think access points should use Poe (better power consumption, better connectivity, less cable runs etc )
Speed wise, I'm.in the UK so 2.5gb ports would be ok, maybe 5gb for 5 year future proofing? 10gb I think I'll be waiting a while for!
Cloud managed, linked the Firewalla app and the Firewalla wifi7 Poe APs and I'll sign up for a subscription as I'd be all in on firewalla.
-
For segmentation of networks when VLAN's aren't available on Wi-Fi (eero, etc) when trying to deal with IoT, I would like to see:
- Static MAC-based VLAN assignment
- ACL's for MAC addresses on ports
- Port Isolation. TP-Link example:
https://www.tp-link.com/us/support/faq/525/FYI, newer TP-Link DECO's are getting "Isolated Device" features to assist with IoT support in the absence of VLAN's:
https://community.tp-link.com/us/home/kb/detail/412694P.S. You might make some eero owners happy if you group certain features together for configuration that interfere with TrueMesh and must therefore be disabled in-between eeros; VLANs, anything that might add DSCP/ToS tags, loop avoidance, all forms of STP and all loop prevention features.
-
At least 12 POE ports mandatory for all existing ports with option to cut off POE individuality for each port (very important for me), at least 4 10G ports for connecting to Firewalla and another switch plus to a NAS and to one computer, remaining ports can be up to whatever you want
-
@firewalla @bryce
I agree, but how much money and power would this take?
Is it in your plans at all?
Can you make a lite version, too?"Bryce
2 days ago
For an 8 port switch 2 x 1gb, 4 x 2.5gb, and 4 x 10gb ports, with an additional 2 sfp+ 10gb ports.All ports and status lights are in the front and power is in the back for a mountable solution, please."
-
Firewalla,
Respectfully, I’m curious what a Firewalla switch will bring to the table that cannot be found from other vendors. Your firewall products definitely have a niche that can’t be found elsewhere, which makes them so desirable. In the case of switches however, there is A LOT of competition. I just wonder what will be offered that one can’t already find in an existing switch.
-
My personal hope would be a tight integration between the switch and firewall through the app. So when you set up a VLAN it would automatically propagate out to all attached switches and AP. You would still likely have to assign a VLAN to a switch port to make devices down it automatically connect to that VLAN, but the actual defining of the VLAN ID and name would hopefully propagate out to the devices on the network making set up easier. Right now when you have different vendors you must define the VLANs on each device individually and make the IDs match.
Perhaps even create Security Group Tagging feature like Cisco has and allow its use across the firewall and switches? SGTs are a lot like VLANs and rules, but you can apply a security rule to a group of devices and not to others on the same VLAN. Where a VLAN is assigned to a switch port, Security Group Tags are assigned to devices. Sort of the same thing but a different way to go about things, and useful for wifi connecting clients that are all connecting on the same AP and SSID. SGTs are used to represent a logical device group instead of a physical device group. And if you assign a device to an SGT, if you then connect it from one switch on one side of the house you another switch on the other side it would still be apart of the same security group and those rule policies still apply to it.
Maybe apply a QoS scheme across the whole network and not just on the firewall for traffic going through it?
Or what if it is an L3 switch, and they make ACL rules available so you can make them in the app but you can make an ACL exactly like a firewall rule and apply them all in the same place on the app but it uses those ACLs on the switch automatically? ACL rules for VLANs are much faster than a firewall rule is so performance is higher.
Or something really crazy that I don't think anyone does yet: What if you could integrate the switches into the app and firewall in a way that you could set up port mirroring, but instead of mirroring traffic to a physical port on the switch it could create a virtual port in the firewall that gets all the mirrored traffic and then you could log all of the traffic via wireshark directly on the firewall? That way you dont have to use a real physical port anywhere or divert traffic to a device for doing some logs like that.
-
A switch with more than 8 ports would be too much for me and likely most “average bear” home users. BUT if there were a purpose built way to slave several 8 port switches together for users to scale as needed that would be both innovative and useful. It could be as simple as recessed and extendable male Ethernet on each side, or top / bottom with corresponding female, jack, and the software to recognize when they are connected. Or it could be very complicated and that is why no one has tried before.There would of course need to be a safety failsafe as someone will most definitely try to build a super switch. POE too please:)
-
Yes you might be right. I have a net gear lined up and am a very brand loyal customer when I find a product I love; in this case, Firewalla . Happy to be corrected , but I think a 16 port switch with 8 PoE needs a fan for cooling? Or at the moment there is not a fan less switch like that yet on the market? I imagine a home user(such as myself ) may not want that buzzing in their office or a poorly ventilated tech closet. It is great Firewalla is making higher speed equipment, but as capabilities go up so do costs making cyber security simple and less affordable.
-
Not double, for all 16 ports you’ll need just one power supply, just 2x10G POE, just 6x2,5G POE ports, just one body case. All of that are the most expensive parts and make the main cost, all I ask is to add on top of that 8 more, not so expensive 2,5G non POE ports, which no need more power just a bit more space, but honestly you can fit all of that in a case similar to Firewala Gold Pro.
Will be duble only if you’ll have to buy two 8 POE port Switches each with its own power supply, each with their own 2x10G very expensive ports and so on.
So no, I think it’s not double of that at all maybe 150$ more at max…
